Is this considered ring in general and/or by the regs?

[JuniorSparky]

Hi everyone,

I was asked to fix a messed up ring. The client doesn't want to tear apart everything and asked if it will comply with the regs if it is done like this - Let's say we have a ring with three points and a spur from each point. The point is that the three points on the ring will be actually three junction boxes (all accessible) and from each one there will be a run/spur to where the socket outlet will be.
It looks weird to me and not sure if I want to do it, but I can't see why it can't be done! I don't have so extensive experience like you all guys, so any thoughts will be appreciated!

Cheers



[telectrix]

as long as each unfused spur has only 1 socket outlet on each, then it complies.



[Paul.M]

JS, are you doing this job off your own back or with supervision? I/we need to Know....



[Hellmooth]

Do you have a regs book?



[telectrix]

i've always got mine to hand,



[Hellmooth]

What edition is that? I just got my new one through.



[Octopus]

Hi everyone,

I was asked to fix a messed up ring. The client doesn't want to tear apart everything and asked if it will comply with the regs if it is done like this - Let's say we have a ring with three points and a spur from each point. The point is that the three points on the ring will be actually three junction boxes (all accessible) and from each one there will be a run/spur to where the socket outlet will be.
It looks weird to me and not sure if I want to do it, but I can't see why it can't be done! I don't have so extensive experience like you all guys, so any thoughts will be appreciated!

Cheers

Sounds like it was wired by a Pole



[telectrix]

i did advance from it 30 years ago to this:

dan dare vs the mekons, great stiuff.



[andyb]

Sounds like it was wired by a Pole

Dancer?



[JuniorSparky]

Thanks guys. Yes, I'll do it myself. Yes, I do have a regs book. Yes, I thought about 1/more socket outlets ..... I feel embarrassed.. really embarrassed! Just opened to check the regs again and I saw the answer of my question was in front of my eyes! Basically I can suggest, depending of the location of these junction position that these can be FCUs and he can use double socket if he wants!

Thank you guys and sorry for wasting your time!

PS: well I don't know who did the installation, but he says that the whole house was done on one circuit breaker, having a ring to one big junction box and from there runs to each socket outlet!!!



[telectrix]

don't be embarrased to ask questions if you are still on a learning curve, as your screen name suggests. that's what us old farts are here for---- to help the young sprogs get it right. :90:



[davesparks]

,
I was asked to fix a messed up ring.

Oooh matron!



[Hellmooth]

i did advance from it 30 years ago to this:

dan dare vs the mekons, great stiuff.

View attachment 30271

Now that that looks worth a read!



[davesparks]

Hi Let's say we have a ring with three points and a spur from each point. The point is that the three points on the ring will be actually three junction boxes (all accessible) and from each one there will be a run/spur to where the socket outlet will be.

No that doesn't comply, you cannot have more spurs than you have points on the ring. As you have no points on the ring you cannot have any spurs.

What exactly is the situation now and what have you been asked to do?

For only 3 twin sockets you could just make it a 20A radial.


Once upon a time, when the ring final circuit was new, the above joint boxes was how it was often installed. But then the iee put a stop to it sometime in the 13th/14th edition era



[Marvo]

I'm interested why they put a stop to that method Dave? It would still have the same balanced current across the two legs of the supply, topographically it's still a ring final in that respect even to the point that if the junction boxes were sockets it would be compliant.
