i=p/u

-
Arms
Joined
Dec 9, 2010
Messages
7,520
Reaction score
816
Location
Northern Ireland
i have been asked to install 10 sockets and 12 spotlights above a cafe which has been derilict for years, what the dude has done is plasterboarded one room and hall in this derilict building above his cafe.. he said i can surface mount the sockets and the spotlights i can rip up floor above to do spotlights , no problem. also at the back of his cafe he had a 20ft container unit to make kitchen bigger and has now built round it and left in place. just the way it is.. he wants an office now(above)..

heres what i propose to do, use 40A breaker in cu , 6mm t&e surface mounted to new 4 way board with 63A 30mA main switch with 2x20A raidials and 6A lighting circuit.

the run isnt long for distribution circuit or radials and reason im using 2 radials in small space is it will save on bending conduit all around room and over the top of a fireplace... just think is best.....

any flaws in my plan, my onlky one is maybe run distribution in 10mm2, and dont worry about surface mounted cable as is the best way. the cafe is the dogs b. looks well but when you go out back trunking and cables everywhere... thanks if you read and if you like i might write a book for yous

ok , this is what ive ended up with, please tell me if im missing anything.Qty. Unit Description Price Per Disc. Total
200ROBUS R201SC−13 DOWNLIGHT 50W CHROME
OSRAM P165FA FLOOD GU10 BASE 240v 50w
CLICK CMA010 PLATESWITCH 1G 1W 10A WHI
CABLE 3183Y 1.5 x 3C WHITE FLEX
MITA RLG20W HLG2 20MM L/G PVC CONDUIT
CLICK WA079 20A J/BOX
CLICK CMA036 SOCKET 2G SWITCHED 13A WHI
CLICK KBU322 2G K/O BOX
CABLE 6242YH 2.5MM TWIN+EARTH GREY
OLYMPI 8 X 1 1/2 C/S
REL AWPRED RED RAWL PLUGS
MITA SBS20W ESB/2 20MM SPACE BAR SADDL
HAGER VH104 CONSUMER UNIT 4 WAY 100A PD
HAGER MTN140 MCB TYPE B SP 40A 6KA
HAGER MTN120 MCB TYPE B SP 20A 6KA
HAGER MTN110 MCB TYPE B SP 10A 6KA
HAGER CDC263U RCCB DP 63A 30MA
CABLE 6.0MM X 3CORE HITUF
REL ARC13 TCA14−20 BLACK CLIPS
MITA PMA20W EMA/2 20MM MALE ADAPTER
THORS 3314030 HOLESAW 20MM
THORS 3312198 HOLESAW 67MM
THORS A1 ARBOR FOR 14−30mm HOLESAWS
THORS A2 ARBOR FOR 32−152mm HOLESAWS

Last edited:
Use heavy gauge conduit, much easier to bend neatly.
Hope you have a decent drill for the holes and some dust collection.
What are you wiring the lights in? 3 core flex?
Are you using any conduit boxes, not sure how far you have to pull.
How has he has plasterboarded the walls do you need dry lining boxes not K/O boxes?

well had my first expierience with wholesalers today... dodgy people, got 3 quotes all varied, il bet you know which one wanted most...... then the 1 i went with brought all materials to counter and then said, dont have this and this and this, what gays

...... then the 1 i went with brought all materials to counter and then said, dont have this and this and this, what gays

im the only wholesaler in the village..
